Relansering av en oppdatert versjon av klassikeren Fire Dragon som ble først lansert i 1989. Har firehjulsdrift og gode off-road kjøreegenskaper. Modellen leveres med lakkert body og en kraftig børstemotor.
Behøves utenom som ikke er inkludert:
2-kanals fjernkontroll og mottaker
7.2V Ni-Mh batteripakke og lader
Farstregulator (ESC)
Styreservo
Superlim (CA Lim)
Spesifikasjoner:
RC bygggesett
Chassis type: Vintage
Skala: 1/10
Lengde: 39 cm
Bredde: 24 cm
Høyde: 13,9 cm
Terreng: Off-Road
Drift: 4WD Firehjulsdrift
Fartsregulator (ikke inkludert)
Batteripakke: 7,2V Ni-Mh med Tamiya-kontakt (ikke inkludert)
Motor: Børstemotor (inkludert)
Lakkert body
Lakk/maling anbefalt av Tamiya:
XF-1 Flat Black
XF-15 Flat Flesh
Informasjon fra Tamiya:
Light a Fire!
This is an updated re-release version of the Fire Dragon, a 4WD buggy originally sold in 1989 and based upon a car in the popular 1980s Japanese comic "Rajicon Boy." Its polycarbonate body features a distinctive swept form, is pre-painted in red, and is even pre-cut for your convenience - just apply the included stickers. An unpainted driver figure is also included for installation in the cockpit. The chassis is an efficient shaft-driven 4WD unit, with front and rear gear differentials in sealed gearboxes, plus 4-wheel independent double wishbone suspension featuring CVA oil dampers. Spike tires give plenty of grip both on- and off-road.
Efficient Shaft-Driven 4WD
The Fire Dragon (2020) chassis features a shaft-driven 4WD drivetrain married to a lightweight and tough bathtub frame that employs front and rear gearboxes with the suspension attached to them; that suspension utilizes upper "I" and lower "H" arms, and offers a ground-hugging drive. Both gearboxes house a gear differential, and are compact to ensure plentiful ground clearance. The kit also features an aluminum motor mount for superior heat dissipation.
Specifications
★Length: 390mm, Width: 240mm, Height: 139mm
★Wheelbase: 260mm
★Minimum ground clearance: 23mm
★Tread: 203mm (front), 194mm (rear)
★Bathtub frame
★Tire width/diameter: 38/83mm (front and rear)
★Shaft-driven 4WD
★3-bevel differential gears (front and rear)
★3-piece steering tie-rod
★4-wheel independent double wishbone suspension
★Gear ratio = 7.68:1
★Type 540 Motor
★Electronic Speed Controller (ESC) is sold separately.
Separately Required Items
★2-channel R/C system w/ESC ★R6/AA/UM3 batteries for transmitter ★Battery pack & charger
